12mm RGBCW LED Tape

Model NST12S-RGBCW · Silicone / PU · 3 trims

Five channels on one 12mm tape: red, green, blue, 2400K warm white, and 6500K cool white. 360 LEDs per meter, 24V DC, 4.8 W/m per channel (24 W/m and 1,281.6 lm/m at full output), CRI above 95 on the whites, 3-step MacAdam binning. Cuts at 50mm, runs to 5m. IP20 base, field-upgradable to IP68. ETL listed.

Beam: 15-45°
Ingress: IP20-65
Trims: 3

Configure this fixture Specs and downloads

Pick trim, ingress rating, beam angle and color temperature. Takes about a minute.

Certified & rated

IP65Wet location

Ratings apply per build. The IP65 rating belongs to the builds that carry it, not to every option on this page.

In the box

Included

LED Strip, 150mm cable

Ordered separately

Power Supply/Transformer

Configurator

Build the fixture, get the order code.

Work down the options below. Anything that cannot combine with your selection dims out, and the code updates as you go. Send it to us and we will quote it.

0 of 7 required

Engine (required)

Required

Body (required)

Required

Color Temp (required)

Required

Driver (required)

Required

Beam (required)

Required

Finish (required)

Required

IP Rating (required)

Required

Options add any

None selected

Order code

NST12S-··-··-··-··-··-··-··

7 required axes remaining

Configured price

$155.00

Photometrics

See what the tape does before you build the cove.

Pick what the tape is doing, how far it sits from the surface it lights, the pocket you are building, a run and a colour temperature. One set of inputs drives all five views: the wash in section, the run with its driver, reels and feeds, the polar distribution, the measured spectrum, and color rendition. Tested IES files for every build are in the downloads below.

What it is doing

Gap to the ceiling

Tape to the fascia

Fascia above the tape

Run length

Beam angle

Colour temperature

Across the ceilingShare of peak

At the wall98%

0.5 m out<1%

1.0 m out<1%

Direct wash ends 12 in out · ceiling halves 0.13 m out, a tenth by 0.29 m

Where the fascia ends the direct wash is geometry, and holds for any tape: the gap times the pocket’s width over the fascia’s height, 12 in out here. What the pocket hands back past that line is an estimate at an assumed 0.8 reflectance for a flat-white pocket, on which about 76% of the tape’s lumens leave the cove. Lux is not shown for either because it needs the tested distribution for this tape, which we publish on the downloads below rather than estimate here. For a layout across a whole plan, send us the drawings.
